UBA 3224 – Class D Power Amp
State of the art digital power amplifier with 2x240W/100V
in compact 1RU size. Latest switching power technology
allows an efficient over 85%. In addition the unit is equipped
with a very efficient low noise cooling.
Secifications:
| Name: | UBA 3224 |
| Item no.: | 104534 |
| Power output: | 2x 240 W / 100 V |
| Input sensitivity: | 775 mV / 10 kOhm |
| Signal-to-noise ratio: | > 85 dB |
| Total Harmonic Distortion (THD): | < 0.1% at 1 kHz/-3 dB, 100 W |
| Power consumption: | 600 W |
| Operating voltage: | 110 V/240 V~ / 50 Hz/60 Hz |
| Connection: | Phoenix terminals |
| Dimensions (in mm): | 482 x 395 x 44 |
| Weight: | 8.3 kg |
